Type | Designed by Duchéne and built in 1925 as a two-seat biplane trainer. |
Engine | 1 70 hp Mark M 5 |
Dimensions | Length 6,02 m , height , span 9,40 m , wing area , |
Weights | Empty 360 kg, fuel 60 kg, oil 5 kg, crew 75 kg, load 110 kg, normal flying weight 610 kg |
Performance | Max. speed 110 km/h at sea level, cruising speed 90 km/h at sea level, service ceiling 3000 m, range 400 km, requred length for start 35 m, for landing 30 m, landing speed 45 km/h |
Type | Werk.Nr | Registration | History |
220 | D-800 | ||
227 | D-998 | Belonged to K. Bruegmann, Breslau in Febr. 1928, Bund.Deutscher Flieger Ortsgruppe Leobscutz Destroyed in Aug. 1929 |
