Type 5-seat medium bomber
Engine 2 DB 600Ga
Dimensions Length 16,40 m , height  4,20  m,  span  22,60 m, wing area  87,60 m2 ,
Weights Empty 6000 kg, loaded 8800 kg , max. take off weight
Performance Max.. speed 410 km/h at 4000 m , cruising speed  , range 1065 km, endurance  , service ceiling 7000 m  , climb
Armament 1 20 mm MG FF, 6 7,92 mm MG 15. Bombload 2000 kg
Type Werk.Nr Registration History
D 2101
2102
2103
2104
2105
2106
2107
2108
2109
2110
2111
2112
2113
2114
2115
2116
2117
2118
2119
2120
2125
2126
2127
2445
2447
2449
2451
2453
2455
2457
The extensive testing program resulted in another bomber version, the He 111 D-0. Its progenitor was the the V9 D-AQOX with more powerful DB 600Ga engines .
In fact, that was the only difference from the He 111B. which allowed a speedy commencement of the production of the new version. No constructional changes were required, so production did not need to be interrupted in order to the incorporate new parts assembly. The new engines accelerated the He 111D to a maximum speed of 410 kph.
Overnight, DB 600 engines were now in short supply. With only a few He 111 D-0 rolled out of rhe factory by April 1937, the production of this version had suddenly been put under a queslion mark and was evenlually lo be abandoned altogether.. He 111 Ds that had been builr never found their way to combat units; they were assigned to lesting and experimenlal purposes.
