Type |
4-seat bomber , transport |
Engine |
2 Siemens Jupiter VI 6,3Z with 4-bladed wooden Dornier propellers |
Dimensions |
Length 18,64 m , height 6,32 m , span 28 m , wing area 111 m2 , |
Weights |
Empty 4660 kg, loaded 8000 kg , max. take off weight |
Performance |
Max.. speed at sea level 242 km/h, at 1000 m 241 km/h, at 2000 m 234 km/h, at 3000 m 220 km/h, at 4000 m 212 km/h, cruising speed 212 km/h,landing speed 100 km/h, range 1200 km, endurance , service ceiling 4700 m , climb 1000 m 4 min 24 sec., to 2000 m 10 min. 54 sec., to 3000 m 22 min. 12 sec., to 4000 m 50 min. 30 sec- |
Armament |
|
