Type |
6 seat long-range oversea reconnaissance plane |
Engine |
4 Maybach Mb.IVa Propellers: 4-bladed Fixed pitch wooden, 3 m diameter Propeller centres 3.3 m apart |
Dimensions |
Length: 22.75 m height: 8.20 m wingspan: 37 m wing area: 226 m2 |
Weights |
Empty weight: 7865 kg loaded 10,670 kg Fuel capacity: 2,260 kg / 3,140 l |
Performance |
Maximum speed: 135 km/h endurance: 10 hours time to altitude: 2,000 m in 35 mins |
Armament |
Provision for one machine-gun in the nose and two machine-guns in top of the fuselage |
