Type |
Single seat fighter |
Engine |
1 BMW VI 7.3 Z with 2-bladed fixed-pitch propeller |
Dimensions |
Length 7,5 m, height 3,3 m , span upper 10,0 m ,lower 8,0 m, wing area 26,72 m2 , |
Weights |
Empty 1210 kg, loaded 1630 kg , max. take off weight fuel 390 l |
Performance |
Max.. speed 322 km/h at sea level,landing speed 95 km/h, cruising speed , range , endurance , service ceiling 8400 m , climb to 3000 m 4,3 min., to 1000 m 1,2 min., to 3000 m 3 min. 54 sec., to 5000 m 9,4 min., to 6000 m 12,0 min. |
Armament |
Provision for 2 machine guns |
