Type |
a Two seat reconnaissance aircraft |
b Two seat reconnaissance aircraft |
Engine |
1 BMW VI |
1 Siemens Jupiter VI |
Dimensions |
Length 9,90 m , height , span upper 11,5 m ,lower 10,0 m, wing area 34,57 m2 , |
Length 9,81 m , height , span upper 11,5 m ,lower 10,0 m , wing area 34,57 m2 , |
Weights |
Empty 1780 kg, loaded 2570 kg , max. take off weight , fuel 550 l |
Empty 1700 kg, loaded 2436 kg , max. take off weight , fuel 550 l |
Performance |
Max.. speed 240 km/h at sea level, cruising speed 220 km/h at sea level , landing speed 95km/h, range 1070 km , endurance , service ceiling 5000 m , climb to 1000 m 2,8 min., to 2000 m 6,8 min., to 3000 m 14,8 min. |
Max.. speed 232 km/h at sea level, cruising speed 210 km/h at sea level , range 1020 km , endurance , service ceiling 5000 m , climb to 1000 m 3,2 min., to 2000 m 7,8 min., to 3000 m 16,2 min. |
