Type |
a Two-seat reconnaissance seaplane |
B Two-seat reconnaissance seaplane |
Engine |
1 Gnome-Rhône 9Ak Jupiter VI with 2-bladed propeller |
Dimensions |
Length 10,25 m , height 4,32 m , span upper 12,40 m , lower 11,0 m, wing area 46,89 m2 , |
Length 10,38 m , height 4,32 m , span upper 12,40 m ,lower 12,40 m, wing area 44,70 m2 , |
Weights |
Empty 1695 kg, loaded 2482 kg, max. take off weight |
Empty 1733 kg, loaded 2529 kg, max. take off weight |
Performance |
Max.. speed 200 km/h, cruising speed 185 km/h , landing speed 90 km/h, range 590 km, endurance 3,0 h , service ceiling 4500 m , climb to 1000 m 5 min., to 2000 m 11,0 min. |
Max.. speed 211 km/h, cruising speed 185 km/h ,landing speed 100 km/h, range 700 km, endurance 5,0 h , service ceiling 4650 m , climb to 1000 m 4,2 min. ., to 2000 m 9,4 min. |
Armament |
Optional :1 fixed and 2 movable machine guns |
