| Type |
Single seat fighter |
| Engine |
1 Fiat RA.1050 R.C.58 Tifone with a 3-bladed constant speed propeller |
| Dimensions |
Length 9,37 m , height 3,13 m , span 11,85 m , wing area 21,11 m2 , |
| Weights |
Empty 2630 kg, loaded 3520 kg , max. take off weight 3718 kg |
| Performance |
Max. speed 623 km/h , cruising speed , range 1200 km, ferry range with 2 100 l drop tanks 1650 km endurance , service ceiling 12750 m , climb to 6000 m 5 min. 50 sec., to 7000 m 8 min. 34 sec. |
| Armament |
1 20 mm MG 151/20 cannon, engine-mounted {250 rounds)
4 12.7 mm Breda-SAFAT machine guns, two in the upper engine cowling, two in the lower cowling/wing roots (300 rpg) |
