Type |
History |
M V1 |
Bomber corresponding to K-1, but 2x DB 603A, V-prototypes |
M-1 |
Bomber corresponding to K-1 with DB 603A, series from the end of 1942 |
M-1/U1 |
Bomber equivalent to K-1 and additional fuselage - ETC. |
M-1/R6 |
Reconnaissance aircraft equivalent to K-1 /R6, but DB 603A. |
M-1/R16 |
Bomber equivalent to K-1, but with additional wing ETC. |
M-1/R18 |
Bomber with modified bomb compartment, 4 racks for 50/XD bombs, otherwise like K-1. |
M-1/R19 |
Bombers with rear-mounted armament, such as K-1 and K-2/19. |
M-1/R20 |
Bomber with rear-mounted armament, like K-1. |
M V13 |
High-altitude bomber, test aircraft, DB 603A with charger. |
M V14 |
High-altitude bomber, experimental aircraft, corresponding to V 13. |
M-2 |
Torpedo bomber, corresponding to K-2, with DB 603A with serial installation of the Rüstsatz R4. |
M-5 |
Glide bomb carrier, similar to M-1. |
M-5/R15 |
Glide bomb carrier (as a converted machine). |
M-8 |
Horizontal bomber with improved equipment. similar to M-1 and M-2. |
M-9 |
Combat aircraft for special missions, largely equivalent to K-3, but with DB 603A. |
M-11 |
Bomber corresponding to M-1 with wings of K2 and DB 603A. |
M-11/R19 |
Bomber corresponds to M-11 with rear armament. |
M-11/R25 |
Dive bomber with parachute brake. |
