Type |
2-seat floatplane mail carrier and reconnaissance aircraft |
Engine |
1 Hispano-Suiza 12 Jb 2-bladed wooden propeller , 2 Rateau lamella coolers in the lower wing |
Dimensions |
Length 9.98 m, height 4.18 m, span 13.0 m, wing area 47.44 m2 |
Weights |
Empty 1310 kg, load 690 kg, flying weight 2000 kg |
Performance |
Max. speed 200 km/h, cruising speed 175 km/h, landing speed 75 km/h, range 700 km, climb to 1000 m 4 min., from 1000 m to 2000 m 4 min., from 2000 m to 3000 m 6 min. |
Armament |
(Proposed) 1 fixed forward firing MG and 1 MG in a dorsal position |
