| Type |
2-seat reconnaissance |
2-seat reconnaissance floatplane , W |
| Engine |
1 BMW VI 6.0 Z with 2-bladed wooden prop. Ø 3.92 m and pitch 2.76 m |
| Dimensions |
Length , height , span 14.0 m, wingarea 49.5 m2 |
Length 11.56 m, height 4.43 m, span 14.0 m, wingarea 49.5 m2 |
| Weights |
Empty 2264 kg, crew 160 kg, fuel and oil 481 kg, flying weight 3000 kg
|
Empty 2564 kg, crew 160 kg, fuel and oil 481 kg, flying weight 3300 kg, fuel 880 l, oil 55 l |
| Performance |
Max. speed at sea level 255 km/h, climb to 1000 m 3 min., cruising speed 225 km/h, landing speed 110 km/h
|
Max. speed at sea level 243 km/h, at 2000 m 238 km/h, at 4000 m 219 km/h, at 5000 m 195 km/h, climb to 1000 m 3 min.36 sec., to 2000 m 8 min., to 4000 m 21 min. 42 sec., to 5000 m 44 min., cruising speed 180 km/h, landing speed 116 km/h, range 1050 km, service ceiling 5360 m, take off run 360 m |
