Type |
2-seat light bomber |
Engine |
1 CKD Praga-Isotta Fraschini Asso 750 W-18 with 2-bladed wooden fixed-pitch propeller |
Dimensions |
Length 12,09 m , height 3,73 m , span 16,99 m , wing area 58,7 m2 , |
Weights |
Empty 2578 kg, loaded 4345 kg , max. take off weight |
Performance |
Max.. speed 265 km/h , cruising speed , range 845 km, endurance , service ceiling 5600 m , climb 2,5 m/sec. |
Armament |
2 forward-firing 7.92 mm vz.30 (Česká zbrojovka Strakonice) machine guns 2 7.92 mm vz.30 (Česká zbrojovka Strakonice) in ring mount for observer Bombs: 500 kg (1,100 lb) |
