Meindl/van Nes A VII
Type
1 + 1-2 seat sportplane
Engine
1 Armstrong Siddeley Genet Mk IIA (Werk.Nr. 4403) with a fixed 2-bladed wooden prop.
Dimensions
Length 7,45 m , height 2,65 m ,  span 10,50 m , wing area 16,20 m2  ,
Weights
Empty 372 kg, loaded  , max. take off weight  682 kg (3-seated), max. take off weight  570 kg (2-seated)
Performance
Max.. speed  160 km/h, cruising speed 144 km/h , range 570 km, endurance 4 h , service ceiling  5650 m (2-seated), 4600 m (3-seated), climb 2-seated
3,9 m/sec., 3-seated 2,7 m/sec., to 1000 m 3 min. 42 sec.  (2-seated), 5 min. 12 sec. (3-seated),
Type
Werk.Nr
Registration
History

3
A-138, OE-DOL, D-EDOL
