Type |
Two seat trainer |
Engine |
1 Siemens Sh 5 |
1 Siemens Sh 11 |
1 Siemens Sh 13 |
Dimensions |
Length 6.72 m, height 2.62 m, span 10.10 m, wing area 24.7 m2, aspect ratio 4.1 |
Weights |
Empty 530 kg, fuel 55 kg, oil 5 kg, load 220 kg, flying weight 750kg, wing loading 30.40 kg/m2 |
Empty 554 kg, flying weight 774 kg |
Empty 510 kg, flying weight 730 kg |
Performance |
Max. speed 115 km/h, cruising speed 100 km/h, climb 1.65 m/sec, to 1000 m 10 min., service ceiling 2400 m, range 350 km, landing speed 50 km/h |
Max. speed 125 km/h |
Max. speed 110 km/h |
Type |
Werk.Nr |
Registration |
History |
|
148 |
D-769 |
Sh 11 until May 1929, Sh 5 until Nov. 1931, finally Sh 11. From Febr. 1928 registered to Sportflug für Mittelfranken und Oberpfalz, Fürth |
|
162 |
D-595 |
Sh 5 engine until June 1929, from March 1932 Sh 11.To Nordbayerischer Verkehrsflug GmbH 25/3 1926. From Febr. 1928 registered to Sportflug für Mittelfranken und Oberpfalz, Fürth |
|
164 |
D-598 |
Sh 5 until March 1932, later Sh 14. Registered to H. Meisterknecht, Halle from May 1928.From March 1929 at Fliegerhorst Nordmark, Altona |
|
176 |
D-772 |
Sh 11 engine until Sept. 1928, Sh 5 to Aug.1929, finally Sh 13. Registered to Fliegerschule Auffahrt Münster/Westfalen in Febr. 1928. From Sept. 1928 to L. V. GmbH Münster. Flying certification withdrawn April 1932 |
|
177 |
D-825 |
Febr. 1928 Unterfränkisher Sportflug, Würzburg until Dec. 1932. To DLV e. V. Adlershof |
|
178 |
D-808 |
Febr. 1928 Aero Express, Leipzig until Aug.1933. To DLV e. V. Berlin |
|
180 |
D-491 |
Sh 5 engine until June 1932, after that Sh 13. Belonged to Gruppe Oberschlesien, Gleiwitz of the DLV |
|
182 |
D-930 |
Sh 11 engine. Registered to Verein für Luftfahrt, München-Gladbach |
|
183 |
D-128 |
Sh 5 engine until Febr. 1930, Sh 11 until March 1931 finally Sh 5. Registered Sept. 1928 to Sportflug GmbH, Berlin. From Febr. 1930 to DLV , Hubach/Kassel. To L. Mayer, Glessen. Destroyed April 1932. |
|
203 |
D-1253 |
S 11 engine until July 1932, finally Sh 14. Registered to O. Schön, Düsseldorf in Febr. 1928. From June 1931 to Verein für Luftfahrt, Gladbach-Rheydt |
|
|
D-844 |
|
|
|
D-845 |
|
|
|
D-573 |
|
|
|
D-799 , A-92 |
To DLV-Ortsgruppe Hof. To Bayerischer Sportflug, Wurzburg. Sold to Austria April 1930 |
|
|
D-768 |
|
